Round Aquaculture Tank & Square Aquaculture Tank

The Space foldable aquaculture tank is designed to create aquaculture facilities for a variety of fisheries and shrimp farms. There are two types of choice – square type and round type. The size capacity range is 700L – 500,000L and the dimension are customized. It is with low construction cost, a low running cost which compares with the traditional fish pond and plastic aquaculture tank.

The tank fabric is constructed from durable PVC with excellent resistance to hydrocarbons and UV radiation. The tank frame is manufactured from hot-dip galvanized steel tube giving a strong support to the tank. Each vertical supporting arm has a base plate supported by a horizontal tension section.

Round Aquaculture Tank

Features and Benefits

Flexible, modular and compact
Easy and fast to assemble, no tools required
Durable PVC fabric
Hydrocarbons and UV resistant
Sturdy Steel Frame
Ground canvas, cover and storage bag(Optional)

Model	Dia	Height	Liters	US GAL	UK GAL	CBM
SBAGR	2.1	1.2	4156L	1098	914	4.2
	2.5	1.2	5890L	1556	1296	5.9
	3	1.2	8482L	2241	1866	8.5
	3.4	1.2	10895L	2878	2397	10.9
	3.8	1.2	13609L	3595	2994	13.6
	4.3	1.2	17426L	4603	3833	17.4
	5.1	1.2	24513L	6476	5392	24.5
	5.5	1.2	28509L	7531	6271	28.5
	6	1.2	33928L	8963	7463	33.9

Square Aquaculture Tank

Features and Benefits

Flexible, modular and compact
Easy and fast to assemble, no tools required
Durable PVC fabric
Hydrocarbons and UV resistant
Sturdy Steel Frame
Ground canvas, cover and storage bag(Optional)

Model	Length	Height	Width	Liters	US GAL	UK GAL
SBAGS	1	1	1.2	1200L	317	264
	2	2	1.2	4800L	1268	1056
	3	3	1.2	10800L	2853	2376
	4	4	1.2	19200L	5072	4223
	5	5	1.2	30000L	7925	6599
	6	6	1.2	43200L	11412	9503
	1	1	1.5	1500L	396	330
	2	2	1.5	6000L	1585	1320
	3	3	1.5	13500L	3566	2970
